Dimensions (mm):560D x 643W x 534H -
Installation : Suspended, wall, frame, or
duct mounted - Unit weight (kg) : 50 Kg -
Input voltage : 220-240V/50Hz/1PH -
Ionizer/collector output voltage : 12kV/6kV
- Product power (w) : 30 - Number of cells :
1 - Pressure drop (Pa) : ≤65 - Flange size
(mm) : 499 x 534 - Controls : Power switch
with an indicator light - Pre-filter : 460L x
460W x 22.2D Standard aluminum mesh
Heavy oil filter (optional) - Primary filter :
Standard forever filter - electronic ionizer/
collector cell - After-filter : Activated
carbon plate filter (optional) - Power
supply : High-frequency solid- state design -
Efficiency : To 95% based on ASHRAE 52.2
To 99% for double pass (calculated) -
Construction : Welded galvanized steel,
1.2mm (18 gauge) top/bottom, 1.5mm (16
gauge) columns - Finish : Blue epoxy
powder coating (RAL 5017) - Particle size :
0.01 to 10 microns - Genera : Multiple units
can be joined together for increased
volume or higher frequency
